Deadending Clevis

Description

Technical Parameters and Drawings

Notes:

1. Tolerance: ±5%

2. All dimensions are in Inch except for marked.

3. Customized sizes are available at request.

Product Description:

Deadending clevises without a spool are produced to deadend suspension insulators and guyings with extension link fittings.

Clevises are assembled with 5/8” cotter bolts or cotter pins.

Material steel is hot dip galvanized to ASTM A153.

The above are typical only, please consult Shanghai Herrajes for further information.

Product Details:

Name: deadending clevis, dead end clevis, wireholder clevis, steel clevis, deadend clevis

HS code: 7326901900

Model:

Package: bulk packing; palletized; as required

Trademark: HE, as required

Origin: China

Raw material: ASTM A536

Finish: hot dip galvanized

ODM&OEM service: yes

Sample: available, FOC

Payment term: T/T, 30% prepayment and 70% balance against B/L

Certificate: ISO

Delivery time: 20-40 days

MOQ: 500kgs

Export term: FOB; CIF

Production capacity pcs/day: 2000

Pin dia. in: 5/8

Steel size in: 3/16×1 1/2

Extension in: 3 3/4,etc.

Mounting hole dia. in: 13/16

Cotter pin in: 5/8
