Square Meter Boxes

Description

Technical Parameters and Drawings

HE Code	Description	H	W	D	Hub size
MBS01	200 Amps,240/600 V,Single phase,3 wires,4 terminals,Ring type, phosphated treatment	382	218	137	2″
MBS02	200 Amps,240/600 V,Single phase,3 wires,4 terminals,Ringless, phosphated treatment	382	218	137	2″
MBS03	200 Amps,240/600 V,Single phase,3 wires,4 terminals,Ringless, phosphated treatment	398	284	115	2″
MBS04	200 Amps,240/600 V,3 phase,4 wires,7 terminals,Ring type, phosphated treatment	382	218	137	2″
MBS05	200 Amps,240/600 V,3 phase,4 wires,7 terminals,Ringless, phosphated treatment	382	218	137	2″

Notes:

1. Tolerance: ±5%

2. All dimensions are in MM.

3. Customized sizes are available at request.

Product Description:

Square meter sockets are available in steel, aluminum and plastic.

Extruded aluminum connectors are tin plated.

Galvanized steel shell is epoxy baked gray powder finished.

Hub size from 1/2″-2 1/2″

The above are typical only, please consult Shanghai Herrajes for further information.

Product Details:

Name: square meter boxes, meter cabinet, single position socket, economy cast socket

HS code: 9028301200

Model: single phase

Package: bulk packing; palletized; as required

Trademark: HE, as required

Origin: China

Raw material: steel

Finish: hot dip galvanized

ODM&OEM service: yes

Sample: available, FOC

Payment term: T/T, 30% prepayment and 70% balance against B/L

Certificate: ISO

Delivery time: 20-40 days

MOQ: 500kgs

Export term: FOB; CIF

Production capacity pcs/day: 2000

Minimum tensile strength lbs.: 7800

Hubs: 2

Amps: 200

Wires: 3, 4

Terminals: 4, 7
